「工程实践」 Three.js + GeoJSON 实现3D地球边界

npm create vite@latest threejs-vue
# 选择框架：Vue
# 选择：TypeScript
  cd threejs-vue
  npm install
  npm run dev

npm install three
npm install --save-dev @types/three

<script setup lang="ts">
import Earth3D from './components/Earth3D.vue'
</script>
<template>
  <Earth3D />
</template>

<template>
    <div class="earth" ref="domRef"></div>
</template>
<script setup lang="ts">
import { onMounted, ref } from 'vue'
import * as THREE from 'three'

const domRef = ref<HTMLElement | null>(null);

const getScene = () => {
    const scene = new THREE.Scene();
    // 场景配置代码...
}

onMounted(() => {
    getScene()
})
</script>

<template>
  <div class="earth" ref="domRef"></div>
</template>
<script setup lang="ts">
  import { onMounted, ref } from 'vue'
  import * as THREE from 'three';
  import { TrackballControls } from 'three/examples/jsm/Addons.js';
  import type { Feature, FeatureCollection } from 'geojson';
  import geoJson from '../utils/world.zh.json';
  import { drawThreeGeo, hasSupportedGeometry } from '../utils/drawGeo';
  import { StarField } from '../utils/starfield';

  const domRef = ref<HTMLElement | null>(null);

  const getScene = () => {
    // 场景、相机、渲染器初始化
    const scene = new THREE.Scene();
    scene.fog = new THREE.FogExp2(0x000000, 0.035);// 添加雾效，它可以在相机附近提供清晰的视野

    const camera = new THREE.PerspectiveCamera(75, window.innerWidth / window.innerHeight, 0.5, 1000);
    camera.position.set(0, 0, 20); // 设置相机位置
    camera.lookAt(0, 0, 0); // 设置相机看向原点

    const renderer = new THREE.WebGLRenderer();// 创建渲染器
    renderer.setSize(window.innerWidth, window.innerHeight);

    const earthNode = domRef.value;// 获取元素节点
    if (earthNode) {// 将渲染器的dom元素添加到目标元素
      earthNode.appendChild(renderer.domElement);
    }

    // 地球创建
    const planet = new THREE.Object3D(); // 创建一个三维空间
    const geometry = new THREE.SphereGeometry(10, 32, 32); // 球体
    const material = new THREE.MeshBasicMaterial({ // 基础材质
      color: 0x333333,
      wireframe: true,
      transparent: true
    });
    const sphere = new THREE.Mesh(geometry, material); //网格模型:组合几何体和材质
    planet.add(sphere); // 添加到三维空间

    // GeoJSON 数据处理
    const worldData = geoJson as (Feature | FeatureCollection);
    if (hasSupportedGeometry(worldData)){
      drawThreeGeo(worldData, 10, 'sphere', {
        color: 0x88aaff
      }, planet);
    }
    // 加入场景
    scene.add(planet);

    // 星空背景
    const starField = new StarField({
      starCount: 1000, // 星星数量
      fieldSize: 100,  // 星空尺寸
      innerRadius: 60, // 在半径60到100之间分布星星
      size: 0.05,      // 单颗星星尺寸
      color: 0x88aaff  // 星星颜色，淡蓝色:88aaff
    });
    starField.addToScene(scene);

    // 相机控制
    const controls = new TrackballControls(camera, renderer.domElement);
    controls.staticMoving = false; // 启用惯性移动。
    controls.dynamicDampingFactor = 0.05; // 动态阻尼因子，默认为 0.2
    controls.noRotate = false; // 启用旋转
    controls.rotateSpeed = 1.0; // 控制旋转速度
    controls.noZoom = false; // 启用缩放
    controls.zoomSpeed = 1.2; // 控制缩放速度
    controls.noPan = false; // 启用平移
    controls.panSpeed = 0.3; // 控制平移速度
    controls.minDistance = 0 // 相机到目标点的最小距离，默认为 0
    controls.maxDistance = 100 // 相机到目标点的最大距离，默认为 Infinity

    // 渲染场景和动画
    const animate = () => {
      controls.update();
      requestAnimationFrame(animate);
      renderer.render(scene, camera);
    }

    // 调用动画函数
    animate();
  }

  onMounted(() => {
    getScene();
  })
</script>
